Opticron MM4 77 ED MM4 77 Fieldscopes are the latest evolution of the MM concept pioneered and developed by Opticron over the past 25 years to meet the ever growing demand for lightweight, space saving high performance field equipment. Combining all the features that have made our 50mm and 60mm travelscopes the #1 choice for thousands of users the world over, the MM4 77 GA ED/45 delivers our maxim; “smaller, lighter, brighter, sharper” to a new audience. These "80mm users" generally want the maximum brightness and magnification available when viewing or recording birds and wildlife from a fixed position. Designed & manufactured in Japan, the all-new 77mm HDF ED optical system delivers a new benchmark for resolution and colour contrast and comfortably outperforms many older Opticron 80mm models. What is more remarkable is the size and weight of the overall package. The MM4 77 GA ED/45 is just 320mm/(12.6”) (1) long and weighs 1259g/(44.4oz)(1) fully amoured. These figures read like a 65mm which cannot deliver the light transmission and apparent resolution of this 80mm class model. Compatible with SDL, HDF T and HR eyepieces, existing fieldscope owners can use eyepieces from other Opticron models with MM4 77 Fieldscopes. Recommended eyepieces include the 40936M SDLv3 18-54x and 40862M HDF T 18-54x. Features Choose any one of the following to go with the scope body ordered (only valid at time of order) 77mm HDF ED APO lens design Fully multi-coated optical system Lightweight polycarbonate and alloy body Fully protected in soft touch textured rubber armour Nitrogen waterproof Wide wheel focuser with accurate 9:1 ratio dual focus system Retractable lens hood Integrated objective lens cover Large footprint +/- 90° rotating tripod sleeve Telephoto option for SLR photography

Specifications	MM4 77 ED 45º	MM4 77 ED
OG Diameter	77mm	77mm
Min Focus (m)	5.5	5.5
Length (mm)	320	320
Weight (g)	1259	1259
Price	£680	£680

Eyepieces
SDL v3	High Definition 'HDF'	High Resolution 'HR'
SDL v3 18x-54x £325	HDF 20xWW £129 HDF 28xWW £120	HR 15xWA / 20xWA(FOV74) £55 HR 20xWA / 25xWA(FOV59) £55 HR 13-39x / 16-48x(FOV52-30) £160

MM4 77 45º - Stay on case Green	£85.00
MM4 77 - Stay on case Green	£85.00

---

Opticron MM4 ED The new MM4 GA ED is the latest evolution of the popular Travelscope concept pioneered by Opticron over 20 years ago. Combining all the features that make our travelscopes the #1 choice for thousands of users the world over, the latest MM4 continues to deliver our maxim; "smaller, lighter, brighter, sharper" to anyone searching for a compact, versatile, high quality instrument for long range, accurate observation while on the move. Designed & manufactured in Japan, the all-new compact HDF ED optical system creates a 50mm that measures 205mm and a 60mm 260mm without eyepiece. Constructed from lightweight materials, an MM4 weighs about the same as pair of 42mm binoculars and can be used without a support for crystal clear flat-field observation at magnifications below 20x. Unlike binoculars, they deliver stunning clarity and definition up to 36x (50mm) and 45x (60mm) when fitted with the HDF T or SDLv2 zoom eyepieces. Compatible with HR, HDF and SDL eyepieces, existing fieldscope owners can use their eyepiece with an MM4 body. Nitrogen waterproof and fully rubber armoured to protect against knocks and bumps, the MM4 has a tripod adapter with +/- 90 degree rotation to ensure set-up in a hide or from a sitting/prone position is quick and easy, while the 8:1 dual focusing system ensures the finest accuracy at all magnifications. Other features include: Super-compact ED “extra low dispersion glass” objective High contrast FMC optical system Close focus to 2.5m (50mm), 3.5m (60mm) Removable rubber objective lens cover Telephotoadapter option 30 year guarantee

Specifications	MM4 50 ED 45º	MM4 50 ED	MM4 60 ED 45º	MM4 60 ED
OG Diameter	50mm	50mm	60mm	60mm
Min Focus (m)	2.5	2.5	3.5	3.5
Length (mm)	205	205	260	260
Weight (g)	619	615	729	720
Price	£340	£340	£440	£440

Eyepieces
SDL v3 Delivering 12-36x (50), 15-45x (60)	High Definition 'HDF'	High Resolution 'HR'
SDL 12x-36x (50) 15x-45x (60) v3 £325	HDF 13xWW(50) 17xWW(60) £129 HDF 18xWW(50) 23xWW(60) £120	HR 15xWA / 20xWA(FOV74) £55 HR 20xWA / 25xWA(FOV59) £55 HR 13-39x / 16-48x(FOV52-30) £160



MM4 50 45º - Stay on case Black	£61.00
MM4 50 - Stay on case Black	£61.00
MM4 50 45º - Stay on case Green	£84.00
MM4 50 - Stay on case Green	£84.00
MM4 60 45º - Stay on case Black	£61.00
MM4 60 - Stay on case Black	£61.00
MM4 60 45º - Stay on case Green	£84.00
MM4 60 - Stay on case Green	£84.00

---



Opticron MM3 80 GA ED Fieldscope The MM3 80 GA ED is the latest evolution of the MM3 concept pioneered and developed by Opticron with the aim of giving customers the best possible performance in the smallest package at the most affordable price. Constructed from polycarbonate and lightweight alloys, the super-compact optical system creates a body under 30cm/12” long - the size of a 65mm from other brands. As you would expect, images are brighter and sharper giving you more distance and a longer working window for accurate observation. Fully rubber armoured, nitrogen waterproof and fitted with dual focusing, the MM3 80 GA ED is compatible with MM3, HR, HDF & SDL eyepieces. Features and specifications at a glance • Super compact 80mm ED lens design • Fully multi-coated optical system • Lightweight polycarbonate and alloy body • Fully protected in textured rubber armour • Nitrogen waterproof • Wide wheel focuser with 8:1 ratio accurate focusing adjuster • Retractable lens hood with integrated rubber objective lens cover • Large footprint +/- 90° rotating tripod sleeve • Accessories for Digiscoping & Telephotography

Specifications	MM3 80 ED 45º	MM3 80 ED
OG Diameter	80mm	80mm
Min Focus (m)	5.9	5.9
Length (mm)	300	300
Weight (g)	1382	1382
Price	£470	£470

Eyepieces
High Definition 'HDF'	High Resolution 'HR'
HDF 20xW £129 HDF 28xW £120	HR 23xWA £55 HR 30xW £55 HR3 20-60x £160

---

Opticron MM3 The MM3 series is the latest evolution of the Travelscope concept pioneered by Opticron nearly 20 years ago with the original Mighty Midget 20x50. Constructed from polycarbonate and lightweight alloys, the optical system is compact enough to create a body only 205mm (8”) long. Weighing 720 without eyepiece an MM3 weighs about as much as pair of standard 42mm binoculars and can be used without a support for crystal clear flat field observation. If like many users your viewing usually requires the stability of tripod or clamp, the models connect via a universal ¼” thread at the base of the tripod sleeve.Rrain and dust proof and protected against knocks and bumps with full-body rubber covering, the MM3 is available in straight-through and 45° angled bodies to suit different applications. Compatiblilty with the full range of HR, HDF and SDL eyepieces also means Opticron fieldscope owners can use their existing eyepieces with a new MM3 body. Features and specifications at a glance: • 60mm objective lens • High contrast fully multi-coated optical system • Accurate 8:1 dual focusing system • Close focus to 3.5 metres - perfect for high magnification detailed observation at close range • Fully armoured body • Tripod adapter with +/- 90 degree rotation • Removable rubber objective lens cover (supplied) • Telephotoadapter options • 30 year guarantee

Specifications	MM3 60 45º	MM3 60
OG Diameter	60mm	60mm
Min Focus (m)	3.5	3.5
Length (mm)	247	252
Weight (g)	727	718
Price	£190	£190

Eyepieces
High Definition 'HDF'	High Resolution 'HR'	MM3 Zoom
HDF 17xWW(60) £129 HDF 23xWW(60) £120	HR 20xWA £55 HR 25xWA £55 HR3 16-48x £160	MM3 Zoom 16-48x Zoom £100.00



MM4 50 45º - Stay on case Black	£61.00
MM4 50 - Stay on case Black	£61.00
MM4 50 45º - Stay on case Green	£84.00
MM4 50 - Stay on case Green	£84.00
MM4 60 45º - Stay on case Black	£61.00
MM4 60 - Stay on case Black	£61.00
MM4 60 45º - Stay on case Green	£84.00
MM4 60 - Stay on case Green	£84.00



---

Bipod & Carry ball for Spotting Scope Rigid aluminum Bipod finished in matt black. Connects to Telescope tripod mounting or independent tripod sleeve using 1/4 inch thread. Supplied complete with 270mm extension pole for use on a bench or table with a usable height range from 265mm to 730mm. Folds up for easy storage. Weight c/w extension pole 1502g.

Stock Code	Price
Bipod & Carry ball for Spotting Scope	£80.00
Bipod & Carry ball for Spotting Scope + Ball & Socket Head	£100.00

---

Eyepiece Cases Water resistant multi-layer padded cases with zip opener and integrated belt loop. (Left) Case #62 Internal dimensions Ø45 x 80mm Accepts; IS, HR, HR2, HDF & HDF T eyepieces (RIght) Case #62B Internal dimensions Ø55x80mm Accepts 40935 SDL eyepiece

Stock Code	Price
Case #62 Internal dimensions Ø45 x 80mm	£12.50
Case #62B Internal dimensions Ø55x80mm	£12.50

---
